Title
Model of a machine drawn by Leonardo Da Vinci
Caption
Screw jack
Model made from a drawing by Leonardo Da Vinci in the Madrid Codex
(Volume 1, folio 26 recto)
Vinci, Leonardiano Museum
Info+
The Codice Atlantico (Atlantic Codex) is a collection of drawings and notes by Leonardo Da Vinci preserved in Milan's Biblioteca Ambrosiana.
Date
15th century
Credit line
Alfredo Dagli Orti/Photo12
Reference
DGL10A01_448
License type
Rights managed
Available size
149,8Mb (5,3Mb) / 21,5in x 27,1in / 6449 x 8117 (300dpi)
