Visualization of Aerodynamic Discharge
Caption
Emission of colored liquid tracers to visualize aerodynamic flows through hydraulic analogy. Cone shaped sheets from the upper delta wing with incidence, at the ONERA.
Info+
- Onera
Credit line
Photo12/Onera
Reference
INV00003_ECOULHYP
Model release
No
License type
Rights managed
Available size
6,7Mb (272,4Kb) / 4,4in x 5,9in / 1324 x 1772 (300dpi)
